Keysight Introduces PAM3 Signaling with GDDR7 Transmitter Compliance Solution for Next-Gen Graphics Memory

Keysight Technologies, Inc. announced its new graphics double data rate 7 (GDDR7) transmitter compliance solution, that accelerates validation of Joint Electron Device Engineering Council (JEDEC) standards for graphics and AI applications.

Click to enlarge

Growing demand for high-performance computing, gaming, and AI platforms is driving memory and GPU vendors to adopt GDDR7, but the transition is creating significant validation challenges. GDDR7’s shift from traditional NRZ to pulse amplitude modulation (PAM3) encoding enables higher bandwidth while reducing channel complexity, but it requires new test approaches to ensure signal integrity and interoperability at ultra-high data rates. The company’s GDDR7 transmitter test solution addresses this bottleneck, enabling organizations to validate designs while accelerating time-to-market.

The firm’s GDDR7 transmitter test solution consists of D9370GDDC software that runs on Keysight’s UXR oscilloscope series and automates debug and characterization of GDDR7 transmitter designs to ensure compliance with JEDEC JESD239 specifications. When paired with the InfiniiMax Ultra Probe Amplifier, 25 GHz Probe, the solution enables accurate PAM3 signal analysis and timing measurements, allowing engineers to validate and optimize high-speed memory transmitter designs for next-gen GPUs and memory devices.

Click to enlarge

Key benefits of the Keysight GDDR7 compliance test solution include:

• Validates PAM3 signaling under real-world conditions: Advanced signal-to-noise-and-distortion ratio (SNDR) measurements account for crosstalk, enabling engineers to identify and resolve signal integrity issues
• Reduces validation time and risk: Automated compliance testing eliminates manual setup and configuration while delivering consistent, repeatable measurements across electrical, timing, jitter, and eye diagrams, helping teams achieve JESD239 compliance faster and with fewer errors
• Design with confidence at 48Gb/s: A low noise measurement floor enables accurate jitter, electrical, and timing analysis of PAM3 encoding, empowering customers to validate next-gen high-speed interfaces reliably and meet performance targets faster

The GDDR7 test solution can be paired with Keysight’s UXR oscilloscope and MX0025A  InfiniiMax Ultra Probe Amplifier, 25 GHz Probe for system debug, validation, and characterization.

Dr. Joachim Peerlings, VP and GM, network and datacenter solutions, Keysight, said: “By bringing precise, PAM3-aware SNDR measurements to GDDR7 compliance, Keysight is helping the industry shorten validation cycles, reduce interoperability risk, and deliver reliable bandwidth despite increasingly complex channels.”

The new solution has been demonstrated at DesignCon 2026, Feb. 24-26.
