IEEE VLSI 2025: SK hynix Presents Future DRAM Technology Roadmap

SK hynix Inc. announced that it presented a new DRAM technology roadmap for the next 30 years and the direction for a sustainable innovation at the IEEE VLSI symposium 2025 ^(*) held in Kyoto, Japan.

Cha Seon Yong, CTO, SK hynix, delivered on June 10th a plenary session on Driving Innovation in DRAM Technology: Towards a Sustainable Future.

In his speech, CTO Cha explained that it is increasingly difficult to improve performance and capacity with scaling through current technology platform ^(**). “In order to overcome such limitations, SK hynix will apply the 4F² VG (Vertical Gate) platform and 3D DRAM technology to technologies of 10-nanometer level or below with innovation in structure, material and components,” he said.

The 4F² ^(***) VG ^(****) platform is a next-gen memory technology that minimizes the cell area of DRAM and enables high-integration, high-speed and low-power through a vertical gate structure.

Currently, 6F² cells are common, but by applying 4F² cell and wafer bonding technology that puts the circuit part below the cell area, cell efficiency and electrical characteristics can be improved.

CTO Cha also introduced 3D DRAM as the main pillar for the future DRAM along with VG. He said that although some in the industry warn of cost increase according to the number of layers stacked, it can be solved by constant technological innovation.

Along with structural breakthrough, the company will also strive to find a new growth engine by sophisticating technologies of critical materials and components of DRAM to lay foundation for the next 30 years.

“Until around 2010, DRAM technology was expected to face limitations at 20 nanometers, but with constant innovation, we have made it this far,” said Cha, CTO. “SK hynix will continue to guide the future of long-term technological innovation to be a milestone for young engineers in the field of DRAM and maintain cooperation within the industry to bring future of DRAM into reality.“

On the last day of the event, Joodong Park, VP, who leads the next-gen DRAM TF, will present his findings from a recent research on how VG and wafer bonding technology affect the electrical characteristics of DRAM.

^(*) IEEE VLSI (Institute of Electrical and Electronics Engineers Very Large Scale Integration) symposium: One of the most prestigious academic events in the field of semiconductor circuit and process technology, presenting academic achievement in next-gen semiconductor, AI, memory chip and packaging. The symposium is held in turn in United States and Japan annually.
^(**) Tech Platform: A technological framework that can be applied to various generations of products
^(***) 4F²: The area occupied by one cell, a unit to store data, is indicated as F². F indicates the minimum feature size of a semiconductor. Therefore, 4F² is an integration technology to put more cells in a chip which one cell occupies an area of 2F by 2F.
^(****) VG (Vertical Gate): A structure that a gate, which acts as a switch of a transistor, is vertically placed and surrounded by channels. Currently, it is a flat structure where a gate is laid horizontally on top of channels.
