General Micro Systems Launches Military-Focused X9 Spider Thunderbolt 4 Portable Storage Rugged System

General Micro Systems, Inc. (GMS) announced its rugged, military-focused X9 Spider Storage system intended for sensor data recorders, AI datasets, NAS, and data payload ‘sneaker net’ portable data movement.

As a critical component within GMS’ X9 Spider Thunderbolt 4 technology-based open distributed computing architecture (DCA), this X9 Storage includes a 4 or 8 drive removable cartridge supporting secure 2.5-inch or M.2 SSD. The small form factor (SFF) system offers a 128TB (maximum) of removable storage capacity, CSfC or FIPS-140-2 secure encrypted SSDs, and up to 80Gb/s of data I/O streaming.

“Next-generation AI, sensor fusion, and autonomous vehicle applications demand data capacities that far surpass traditional portable mass storage solutions,” said Ben Sharfi, CEO and chief architect. “The X9 Spider Storage module combines massive storage with over 5,000 mating cycles and ultra-fast Thunderbolt 4 I/O ports inside fully sealed, ruggedized, and removable canister cartridges – the perfect choice to support harsh, demanding in-field data operations.”The drives can be configured in RAID array(s) for fault tolerance or data recorder striping, and have advanced sanitization options for modern cybersecurity requirements“

X9 Spider Storage system front and rear

Built to deliver a portable storage solution, the device uses proven high-cycle, high-reliability connectors for the canister and a miniature SFF system size to enable any vehicle, system or personnel to move massive amounts of data between locations. As today’s military computing systems are essentially data collection and processing platforms – such as mission data transfer units, autonomous ground vehicles, unmanned aerial systems (UAS), and generative AI processors – storage solutions must meet significant storage requirements while meeting size, weight and power (SWaP) constraints. As well, the data ‘pipes’ delivering data to/from the drives must be fast enough to keep up with modern SSD read/write speeds.

Based on GMS open Distributed Computer Architecture (DCA) of entire X9 family of SFF modules, X9 Spider Storage highlights include:

• Highest SWaP high-performance rugged storage
• 6”x4.75”x2” at 2lbs.
• Up to 100W downstream power
• High reliability removable canister cartridge with 5K mating cycles
• Supports 4xNVMe (x4 PCIe) or SATA drives
• Alternatively, supports 8xM.2 SSD drives
• Configurability as RAID-0/1 under host control; optional SATA controller
• Dual Thunderbolt 4 I/O ports with 100W power delivery
• Fully sealed, rugged storage canister and locking lever with Tamper Proof Security
• Patent-pending QuadroLock active wedge lock technology, enabling multiple modules to be combined for thermal sharing while withstanding severe shock, vibration and harshness envelopes



Constructing unique storage architectures
What makes X9 Storage unique and compelling is the amount of data carried in a single portable canister (up to 128TB), as well as the dual Thunderbolt 4 ports. An interface jointly designed by Apple Computer and Intel, Thunderbolt 4 technology is a 40Gb/s data ‘pipe’ that carries multiple video streams, PCIe data, 10Gb/s networking, USB, and up to 100W of power. One Thunderbolt input port can be used for data read/write, while the 2nd port can be used for daisy-chaining additional downstream X9 products – including oneor more additional X9 Storage systems.

This creates unique architectures that expand a systems storage ‘array’ into many removable canisters, or provides for fault tolerance and redundancy, or enables larger RAID arrays. The possibilities are limitless, all based on the X9 distributed computing architecture. Moreover, any COTS Thunderbolt device can be added to the system in a guaranteed plug-and-play fashion and each is immediately recognized by a system host CPU.

Cybersecurity features in X9 Storage protect data in several ways, integrating X9 Storage into a broader system architecture. FIPS-140-2 and CSfC drives support NSA-level encryption, plus host-level TPM and key handling provide security root-of-trust authentication. Anti-tamper sensors can interface with GMS SecureDNA at the drive, system, and CPU level for whole-system sanitization. Other custom features are available.

X9 Spider distributed system advantage
The X9 Spider modular, scalable and distributed architecture reduces the development barriers to rugged high-performance computing, high-definition video, sensor processing, AI, battlefield edge processing, storage, display, and I/O. Housed within small, rugged enclosures with uperformance per dollar/watt, all X9 Spider products are modular, expandable, and scalable. The X9 Spider family supports Thunderbolt 4 technology and the company’s patented LightBolt 40Gb/s connections in copper or fiber, with optional 100W per-port power for up-/down-stream sensors and system expansion.

“If you can’t fit a rackmount server with drives, the X9 Storage system is the battlefield choice. Secure CSfC or FIPS drives, flexible SSD options with RAID, high-speed box-level interconnects and exceptional fault tolerance make X9 Storage the only choice for on-the-battlefield, deployed high-density embedded storage,” Sharfi said. “These modules greatly enhance the capacity and reliability of data movement across the battlefield, giving system designers what they need to meet both performance and environmental requirements.”

Environmental specs :

• SwaP-E: Smallest, fully-rugged storage device
• Size: 6”x4.75”x2”
• Weight: 2.1lbs.
• Power: Configurable to 100W or less ‘no Power Delivery’
  110/220 VAC (60Hz) option available
• MIL-STD: MIL-STD: MIL-STD-810, MIL-S-901, MIL-STD-461,
  DO-160, optional MIL-STD-704
• Temperature: Operates over extended temperature -40°C to +85°C

About GMS:

Spider Family X9

It is a rugged server company known as the industry expert in highest-density, modular, compute-intensive, and rugged small form-factor embedded computing systems, servers, and switches. These powerful systems are for demanding C5ISR defense, aerospace, medical, industrial, and energy exploration applications. The company is an IEC, ISO, AS9100, NIST-800-171, and MIL-SPEC supplier with infrastructure and operations for long-life, spec-controlled, and configuration-managed programs. Designed from the ground up to provide the highest performance and functionality in the harshest environments on the planet, the firm’s highly customizable products include GMS Rugged DNA with patented RuggedCool and Diamond RuggedCool2 cooling technology. GMS uses processors from Intel and Nvidia.
