Qnap TL-Rx00PES-RP Series Rackmount PCIe JBOD Storage Enclosures

Qnap Systems, Inc. launched the PCIe JBOD storage enclosures TL-Rx00PES-RP series, featuring PCIe Gen 3 x8, and providing up to 64Gb/s data transfer speed.

TL-R1600PES-RP: 16 drive bays; 3U rackmount model front and rear

TL-R1200PES-RP: 12 drive bays; 2U rackmount model front and rear

Users can expand existing NAS storage volumes to petabytes-class by connecting multiple TL-Rx00PES-RP series, without requiring RAID-rebuilding on the host NAS. The TL-Rx00PES-RP series supports SATA drives, allowing businesses to choose from a range of enterprise HDDs. This series is for businesses who want to archive/back up virtualization applications, surveillance recordings, large data, and multimedia.

“Technological advancement usually comes at the cost of increased storage requirements. Organizations which handle particularly large data sets, such as research institutions and media production companies, require easy-to-scale solutions. Qnap presents the TL-Rx00PES-RP series as a petabyte-class storage solution for them. The TL-Rx00PES-RP series supports SATA drives, which are budget-friendly and available with large capacities,” said Jerry Deng, product manager.

The TL-Rx00PES-RP series turn on/off is linked with the host NAS, which helps to reduce hardware management tasks for IT staff. Storage expansion cards QXP-3X8PES (PCIe Gen 3 x8) or the QXP-3X4PES (PCIe Gen 3 x4) are required for the NAS to scale up with the TL-Rx00PES-RP series expansion enclosures.

TL-Rx00PES-RP series key specifications

Model name	TL-R1600PES-RP	TL-R1200PES-RP
Drive bays/unit	16	12
Max. number of connected JBOD units	12	12
Max. number of total HDDs	192	144
Max. capacity (*)	2.9PB	2.0PB

QXP-3XxPES PCIe expansion cards key specifications

Model name	QXP-3X8PES	QXP-3X4PES
Expansion ports	2	2
Interface	PCIe Gen 3 x8	PCIe Gen 3 x4
Supported cables	CAB-PCIE10M-8644-8X special cables	CAB-PCIE10M-8644-4X special cables

Availability
The TL-Rx00PES-RP series and the companion expansion cards are available.

^(*) Qnap calculated the effective capacity assuming RAID-60 with 22TB HDDs, petabyte-to-petabyte conversion, and using storage utilization processes such as pool over-provisioning.
