From Cambridge University, New Type of Memory Could Reduce Energy Use and Improve Performance

Researchers have developed a new design for computer memory that could both greatly improve performance and reduce the energy demands of internet and communications technologies, which are predicted to consume nearly a 3rd of global electricity within the next 10 years.

The researchers, led by the University of Cambridge, developed a device that processes data in a similar way as the synapses in the human brain. The devices are based on hafnium oxide, a material already used in the semiconductor industry, and tiny self-assembled barriers, which can be raised or lowered to allow electrons to pass.

This method of changing the electrical resistance in computer memory devices, and allowing information processing and memory to exist in the same place, could lead to the development of computer memory devices with far greater density, higher performance and lower energy consumption. The results are reported in the journal Science Advances.

Our data-hungry world has led to a ballooning of energy demands, making it ever more difficult to reduce carbon emissions. Within the next few years, AI, Internet usage, algorithms and other data-driven technologies are expected to consume more than 30% of global electricity.

“To a large extent, this explosion in energy demands is due to shortcomings of current computer memory technologies,” said Dr Markus Hellenbrand,first author, department of materials science and metallurgy, University of Cambridge. “In conventional computing, there’s memory on one side and processing on the other, and data is shuffled back between the two, which takes both energy and time.”

One potential solution to the problem of inefficient computer memory is a new type of technology known as resistive switching memory. Conventional memory devices are capable of two states: one or zero. A functioning resistive switching memory device however, would be capable of a continuous range of states – computer memory devices based on this principle would be capable of far greater density and speed.

“A typical USB stick based on continuous range would be able to hold between ten and 100x more information, for example,” said Hellenbrand.

He and his colleagues developed a prototype device based on hafnium oxide, an insulating material that is already used in the semiconductor industry. The issue with using this material for resistive switching memory applications is known as the uniformity problem. At the atomic level, hafnium oxide has no structure, with the hafnium and oxygen atoms randomly mixed, making it challenging to use for memory applications.

However, the researchers found that by adding barium to thin films of hafnium oxide, some unusual structures started to form, perpendicular to the hafnium oxide plane, in the composite material.

These vertical barium-rich ‘bridges’ are highly structured, and allow electrons to pass through, while the surrounding hafnium oxide remains unstructured. At the point where these bridges meet the device contacts, an energy barrier was created, which electrons can cross. The researchers were able to control the height of this barrier, which in turn changes the electrical resistance of the composite material.

“This allows multiple states to exist in the material, unlike conventional memory which has only two states,” said Hellenbrand.

Unlike other composite materials, which require expensive high-temperature manufacturing methods, these hafnium oxide composites self-assemble at low temperatures. The composite material showed high levels of performance and uniformity, making them highly promising for next-generation memory applications.

A patent on the technology has been filed by Cambridge Enterprise, the University’s commercialisation arm.

“What’s really exciting about these materials is they can work like a synapse in the brain: they can store and process information in the same place, like our brains can, making them highly promising for the rapidly growing AI and machine learning fields,” said Hellenbrand.

The researchers are now working with industry to carry out larger feasibility studies on the materials, in order to understand more clearly how the high-performance structures form. Since hafnium oxide is a material already used in the semiconductor industry, the researchers say it would not be difficult to integrate into existing manufacturing processes.

The research was supported in part by the U.S. National Science Foundation and the Engineering and Physical Sciences Research Council (EPSRC), part of UK Research and Innovation (UKRI).

Article: Thin-film design of amorphous hafnium oxide nanocomposites enabling strong interfacial resistive switching uniformity

Science Advances has published an article written by Markus Hellenbrand, Department of Materials Science & Metallurgy, University of Cambridge, 27 Charles Babbage Rd, Cambridge CB3 0FS, UK., Babak Bakhit, Department of Materials Science & Metallurgy, University of Cambridge, 27 Charles Babbage Rd, Cambridge CB3 0FS, UK, Department of Engineering, University of Cambridge, 9 JJ Thompson Avenue, Cambridge CB3 0FA, UK., and Department of Physics, Linköping University Thin Film Physics Division, 581 83 Linköping, Sweden, Hongyi Dou, School of Materials Engineering, Purdue University, Neil Armstrong Hall of Engineering, 701 West Stadium Avenue, West Lafayette, IN 47907-2045, USA. Ming Xiao, Megan O. Hilln, Zhuotong Sun, Department of Materials Science & Metallurgy, University of Cambridge, 27 Charles Babbage Rd, Cambridge CB3 0FS, UK., Adnan Mehonic, Department of Electronic & Electrical Engineering, University College London, London WC1E 7JE, UK., Aiping Chen, Center for Integrated Nanotechnologies (CINT), Los Alamos National Laboratory, Los Alamos, NM 87545, USA., Quanxi Jia, Department of Materials Design and Innovation, University at Buffalo, 136 Bell Hall, Buffalo, NY 14260, USA., Haiyan Wang, School of Materials Engineering, Purdue University, Neil Armstrong Hall of Engineering, 701 West Stadium Avenue, West Lafayette, IN 47907-2045, USA., and Judith L. MacManus-Driscoll , Department of Materials Science & Metallurgy, University of Cambridge, 27 Charles Babbage Rd, Cambridge CB3 0FS, UK.

Abstract: “A design concept of phase-separated amorphous nanocomposite thin films is presented that realizes interfacial resistive switching (RS) in hafnium oxide–based devices. The films are formed by incorporating an average of 7% Ba into hafnium oxide during pulsed laser deposition at temperatures ≤400°C. The added Ba prevents the films from crystallizing and leads to ∼20-nm-thin films consisting of an amorphous HfO_x host matrix interspersed with ∼2-nm-wide, ∼5-to-10-nm-pitch Ba-rich amorphous nanocolumns penetrating approximately two-thirds through the films. This restricts the RS to an interfacial Schottky-like energy barrier whose magnitude is tuned by ionic migration under an applied electric field. Resulting devices achieve stable cycle-to-cycle, device-to-device, and sample-to-sample reproducibility with a measured switching endurance of ≥10⁴ cycles for a memory window ≥10 at switching voltages of ±2 V. Each device can be set to multiple intermediate resistance states, which enables synaptic spike-timing–dependent plasticity. The presented concept unlocks additional design variables for RS devices.“
