Availability of SANBlaze SBExpress-DT5 PCIe 5.0 NVMe SSD Validation Test System

SANBlaze Technology Inc. announced availability of its SBExpress-DT5, a complete turnkey PCIe 5.0 NVMe SSD validation test system.

The SBExpress-DT5 system works in conjunction with the company’s Certified by SANBlaze Test Suite, bringing enterprise NVMe validation to the developer’s desktop. The system is self-contained, quiet, and portable, or a work-from-home environment or traveling to customer sites.

System includes advanced capabilities, integration with SerialTek protocol analyzer
The 6th gen SBExpress-DT5 is both evolutionary, growing from a family of widely deployed predecessors, and innovative, with advanced test capabilities, including Vendor Defined Messaging (VDM) testing support for NVMe-MI over PCIe, and both in-band and SMBus test capabilities. All features of the Certified by SANBlaze Enterprise Test Suite are completely supported at PCIe 5.0 speed. The system integrates with SerialTek’s Kodiak PCIe 5.0 protocol analysis system, providing users with test, debug, and analysis capabilities.

Riser technology
The SBExpress-DT5 employs the company’s proprietary riser technology and uses the same set of NVMe PCIe 5.0 risers as the 16-drive RM5 (rackmount) system. All the firm’s risers are capable of single- and dual-port operation and can switch on-the-fly under software control. Risers are available for all NVMe form factors at PCIe 5.0 speed.

SBExpress Manager with Certified by SANBlaze automated test suite
Click to enlarge

Features and capabilities
The SBExpress-DT supports the following features and capabilities:

U.2/E3 single/dual port
All EDSFF form factors
Certified by SANBlaze test suite, with automated report generation and performance plotting
L1.1 and L1.2 Low Power State testing with CLKREQ monitor
Vendor Defined Message (VDM) testing
SR-IOV and multi-root testing
SMBus testing up to 1MHz
MI/MCTP testing over SMBus, VDM, and in-band transports
Power On/Off testing under SW control, all devices
Clock disable testing to all devices
Hardware PERST testing to all devices
Single-/dual-port testing on-the-fly under software control
SRIS/SRNS and SSC clock mode testing (see whitepaper)
Power monitoring of each device under test
PCIe 5.0 bandwidth (PCIe 5.0 x4) to each riser and PCIe 5.0 x16 to root complex
Remote system control for power up/down/reset
PCIe 5.0 x16 ‘Top Slot’ for PCIe Add-In Card (AIC) testing (e.g., FPGA or PCIe Analyzer)
Python APIs for full system control and integration into corporate test infrastructure

Capabilities are for variety of teams
The SBExpress-DT5 proves useful for a variety of teams, including firmware, manufacturing, development engineers, systems engineers, and field application engineers. Analysis tasks are automated with built-in error detection triggering, leading to fast and accurate problem resolution.

The SBExpress-DT5 PCIe 5.0 desktop NVMe SSD test system is shipping with minimal lead times.
