Keysight Technologies Test and Measurement Solutions for USB4 V2.0 Spec at 80Gb/s

Keysight Technologies, Inc. announced simulation and test and measurement solutions that accelerate the development, implementation, and deployment of USB 80Gb/s compatible devices.

D9050USBC Transmitter test application

USB4 Version 2.0 spec enables a plug-and-play interface for inter-digital communication, offering advantages in bandwidth and data delivery. The company’s industry collaborations, coupled with R&D efforts, have enabled the company to deliver solutions for design characterization and validation for USB 80Gb/s. As a result, an ecosystem built around reversible and backward compatible USB Type-C connectors, consisting of silicon vendors and system integrators, can address a growing digital device market with applications including high-resolution displays and higher-fidelity virtual reality devices.

7019A USB Type-C Active Link Fixture

Specific to USB4 Version 2.0, the company is introducing the D9050USBC Transmitter test application, which automates the testing of measurements required for transmitter compliance and return loss testing for USB 80Gb/s. In addition, the N5991U42A Receiver test application automates the complex calibration and receiver testing of USB 80Gb/s products. The firm’s 7019A USB Type-C Active Link Fixture provides access to all USB Type-C signals in a USB 80Gb/s live link.

N5991U40a USB4 Receiver compliance test software
Click to enlarge

“Visions like the metaverse are part of the next chapter of the world’s digital transformation. A wide range of products, including smartphones, AR/VR devices, computers, tablets, and digital cameras, will rely on this next-generation high-speed digital standard,” says Joachim Peerlings, VP, network and data center solutions, Keysight. “Our commitment to supporting the USB Implementers Forum (USB-IF) and an ecosystem based on the USB4 specification will help drive the adoption of the ubiquitous USB digital connectivity standard.”

D9010USBP USB Protocol Trigger and Decode

In conjunction with the D9010USBP USB Protocol Trigger and Decode, customers can configure protocol-level searches and triggers to debug and decode USB 80Gb/s sideband and high-speed traffic. The firm’s network analyzer application software, such as S96011B Enhanced time-domain analysis with TDR and S94USBCB USB Type-C interconnects compliance test application, simplifies and automates the complex test and characterization process of USB Type-C interconnects compliance testing to support the USB4/USB Type-C test ecosystem.

To enable early design stage simulations as well as extensive system level post-layout analysis, the company’s PathWave Advanced Design System, Pathwave ADS, offers a USB4 Version 2.0 IBIS-AMI model maker which facilitates the development of such models for USB 80Gb/s devices. The IBIS-AMI models generated using the W3081E are then used in ChannelSimulation to predict and simulate the BER, eye metrics, and other design parameters.

“USB-IF is committed to working closely with the industry and its members, such as Keysight, who support the delivery of high-performance USB solutions while ensuring reliability, ease-of-use and quality,” said Jeff Ravencraft, president and COO, USB-IF. “Keysight’s early solutions helped facilitate the roll-out of the USB4 specification to accelerate the market introduction of certified USB 80Gb/s products.”

Infinium UXR-Series oscilloscope

Portfolio of high-speed digital instrumentations :

Infinium UXR-Series oscilloscopes deliver accuracy in waveform representation across a wide frequency range.
Vector Network Analyzers measure both the amplitude and phase responses caused by the device. The resulting transmission and reflection measurements, impedance, and s-parameters are then used for compliance tests and characterization.
Integrated Bit Error Ratio Testers (BERTs) identify errors introduced into the system when data is received. This is a critical capability in physical layer characterization, validation, and compliance testing.
