PCI-SIG Developers Conference: Upcoming PCIe 7.0 Specs for Release in 2025

At PCI-SIG Developers Conference 2022, PCI-SIG announced that the PCIe 7.0 specification will double the data rate to 128GT/s and is targeted for release to members in 2025.

Click to enlarge

PCI-SIG technical workgroups will be developing the PCIe 7.0 spec with following feature goals:

• Delivering 128GT/s raw bit rate and up to 512GB/s bi-directionally via x16 configuration

• Utilizing PAM4 (Pulse Amplitude Modulation with 4 levels) signaling

• Focusing on the channel parameters and reach

• Continuing to deliver the low-latency and high-reliability targets

• Improving power efficiency

• Maintaining backwards compatibility with all previous generations of PCIe technology

“For 30 years the guiding principle of PCI-SIG has been, ‘If we build it, they will come,’” observed Nathan Brookwood, research fellow, Insight 64. “Early parallel versions of PCI technology accommodated speeds of hundreds of megabytes/second, well matched to the graphics, storage and networking demands of the 1990s. In 2003, PCI-SIG evolved to a serial design that supported speeds of gigabytes/second to accommodate faster solid-state disks and 100MbE Ethernet. Almost like clockwork, PCI-SIG has doubled PCIe specification bandwidth every three years to meet the challenges of emerging applications and markets. Today’s announcement of PCI-SIG’s plan to double the channel’s speed to 512GB/s (bi-directionally) puts it on track to double PCIe specification performance for another 3-year cycle.”

“With the forthcoming PCIe 7.0 specification, PCI-SIG continues our 30-year commitment to delivering industry-leading specifications that push the boundaries of innovation,” said Al Yanes, president and chairperson, PCI-SIG. “As PCIe technology continues to evolve to meet the high bandwidth demands, our workgroups’ focus will be on channel parameters and reach and improving power efficiency.”

Click to enlarge

The PCIe 7.0 specification is targeted to support emerging applications such as 80 GbE, AI/ML, cloud and quantum computing, and data-intensive markets like hyperscale data centers, HPC and military/aerospace.
