Rambus Demos PCIe 5.0 Digital Controller IP

Rambus Inc. has demonstrated its PCIe 5.0 digital controller IP on FPGA platforms.

PCIe 5.0 performance at 32GT/s in FPGAs is using a soft controller. This capability expands the use models of FPGAs by enabling multi-instance, switching and bridging applications and accelerates the performance of FPGAs used in defense, networking, and test and measurement markets.

“We’ve achieved a new industry benchmark with the demonstration our PCIe 5.0 controller operating at 32 GT/s on popular FPGA platforms,” said Scott Houghton, GM, interface IP. “With the growing importance of FPGAs in markets from defense to the data center, this solution developed by the newly-acquired PLDA team expands the Rambus portfolio and offers the next level of performance for mission-critical applications.“

Features of Rambus PCIe 5.0 digital controller:

• Verified on leading FPGA platforms

• Supports up to 32GT/s data rates

• Backwards compatible to PCIe 4.0 and 3.1/3.0

• Supports Endpoint, Root-port, Dual-mode, and Switch-port configurations

• Supports up to 64 Physical Functions (PF), 512 Virtual Functions (VF)

• Supports AER, ECRC, ECC, MSI, MSI-X, multi-function, crosslink, DOE, CMA over DOE, and other optional features and ECNs
