Curtiss-Wright NSA Approved Common Criteria Certified DTS1 NAS

Curtiss-Wright Corporation‘s Defense Solutions division announced that its Data Transport System (DTS1) NAS device, the embedded industry’s first commercial off-the-shelf (COTS) data-at-rest (DAR) storage solution to support 2 layers of full disk encryption (FDE) in a single device, has been tested and validated for operation at the extended -45ºC to +85ºC operating temperature range per MIL-STD-810G methods and procedures.

This qualification makes the DTS1 for use in the military environments, including high altitude, long endurance (HALE) UAS platforms that must operate as high as 40,000 ft. It is the only Common Criteria certified NAS solution endorsed by the NSA and approved by NATO with 2 certified encryption layers. A cold plate was used for the active cooling testing, and included an integrated DTS1 unit containing a 2TB removable memory cartridge (RMC).

Removable memory cartridge

“We’re very excited that our industry-leading DTS1 network storage and encryption solution has now been validated for deployment in the harshest, most demanding military environments, whether at high altitude, on an unmanned aircraft, or in a space constrained, densely packed ground vehicle deployed in the desert,” said Lynn Bamford, president, defense and power. “With support for actively cooled -45º to +85ºC operation, the certified DTS1 is now able to support a much wider range of environmentally challenging applications, bringing cost-effective, NSA-approved protection of data-at-rest to many more programs.“

About DTS1 two layer encryption approach
The DTS1 incorporates 2 distinct layers of AES 256-bit encryption into one device, making protection of top secret data more cost effective and low risk than traditional NSA Type 1 device development. Both the hardware and software FDE layers have been individually evaluated and certified vs. two Common Criteria protection profiles: (1) collaborative Protection Profile for Full Disk Encryption – Encryption Engine; (2) collaborative Protection Profile for Full Disk Encryption – Authorization Acquisition. The DTS1 has also been approved to be on NATO Information Assurance Product List (NIAPC).

About DTS1
The small DTS1 NAS device, which weighs 3.77lb. (1.71kg) and measures 1.5×5.0 x6.5″ (38.1x127x165.1mm), delivers up to 4TB of SSD with 2 layers of certified encryption. It supports PXE protocol so that network clients on a vehicle or aircraft can quickly boot from the encrypted files on the DTS1’s RMC. This approach facilitates software updates for network clients and reduces SWaP by eliminating the need for individual HDDs in each network client. The company offers 2 mounting options for the DTS1, the VS-DTS1SL-FD, which is designed for cockpit use with DZUS mounting panel, and the VSDTS1SL-F, which uses L-brackets to support flexible mounting within space-constrained platforms. The L-bracket configuration supports mounting on a cold plate for the extended temperature range.

The DTS1 enables any network-enabled device to retrieve stored data or save new captured data. Networked devices using heterogeneous OSs (Linux, VxWorks, Windows, etc.) that support industry standard NAS protocols (i.e., NFS, CIFS, FTP, or HTTP) can store data on and retrieve data from the DTS1. It also supports iSCSI protocol for block storage and PCAP protocol for Ethernet packet capture. The DTS1 is designed to ensure system resiliency and secure operation to thwart cyber attacks.

Common Criteria Advantage
The DTS1 has been evaluated vs. a common set of international standards, enabling system designers in 31 Common Criteria Recognition Agreement (CCRA) member countries in Europe, Middle East, North America, and Asia, and the NATO states, to confidently, without requiring further evaluation, select the device to reduce the development time of their deployed encryption solution. The rugged small form-factor DTS1 NAS device is designed to store and protect large amounts of data on helicopters, fighters, unmanned aerial vehicles (UAV), unmanned underwater vehicles (UUV), unmanned ground vehicles (UGV), and intelligence surveillance reconnaissance (ISR) aircraft that require the protection of sensitive DAR to international standards.

Complete Embedded System Solutions
The DTS1 is designed for rugged applications that require the storage, removal, and transport of data such as cockpit data (mission, map, maintenance), ISR (camera, I&Q, sensors), mobile applications (ground radar, ground mobile, airborne ISR pods), heavy industrial (steel, refinery), and video/audio data collection (flight test instrumentation). The device can be integrated into a rugged deployed system based on the company’s range of open architecture single board computers and DSP modules, as well as integrated mission computers, sensor management systems, and network switches.
