Amfeltec Launches PCIe Gen 3 Carrier Board for Up to 6 M.2 or NGSFF(NF1) PCIe SSD Modules

_{Amfeltec Corporation announced that its PCIe Gen 3 carrier board for up to six M.2 or NGSFF(NF1) PCIe SSD modules is in production.}

_{This is the latest addition to the company’s Squid carrier board family.}

_{When all six SSD modules are mounted, this carrier board utilizes the full bandwidth of the x16 PCIe Gen 3 upstream connection, making it fast. It should be noted that having exactly six SSD modules mounted is necessary to take advantage of the maximum speed – 6 modules happens to be the optimal amount when running in a RAID-0 configuration. The result is a read speed of over 14.2GB/s, and a write speed of over 12.6GB/s.}

_{Due to the company’s patented design, the one-slot-wide carrier board holds all 6 SSD modules while taking up a minimal amount of space. 3 modules are placed on the top (component) side, and 3 on the bottom (soldering) side. This is the first board to support 6 NGSFF(NF1) modules with a width of up to 32mm and length of up to 110mm. The board also has real-time performance and temperature monitoring capability.}

_{“Apart from making the fastest carrier board on the market, we also wanted to provide the greatest storage capacity per slot” says Michael Feldman, president and CTO, Amfeltec, “This becomes obvious through simple math: six 2TB M.2 modules give you a total of 12TB, while six 16TB NGSFF(NF1) modules will give you 96TB. Mounting and unmounting each module on the carrier board couldn’t be easier – you just work with a single screw. This open-concept design ensures maximum air cooling of each module: we don’t need any thermal pads, and we take advantage of both the board’s and the computer’s internal fans.“}

_{This Squid carrier board can operate on any motherboard. It is also in a higher class of boards than those that rely on PCIe bifurcation. This is because those carrier boards are not able to support more than 4 modules per slot due to the natural limitations of PCIe bifurcation itself.}
