Dallas Area Rapid Transit Upgrades Older Backup Appliance and Software

Profile:

Organization: Dallas Area Rapid Transit (DART)
Industry: Regional transit agency
Location: Dallas, TX
Size: Serves more than 220,000 passengers per day

Needs:

Upgrade older backup appliance and software
Platform stability and system supportability
Turnkey solution that includes installation, implementation, training and maintenance support
Integration with existing backup configuration for its radio and CAD/AVL bus dispatch system

Solutions:
STORServer EBA852 enterprise backup appliance with IBM Storwize V3700 20TB Disk Storage and IBM TS3100 tape library.

DART was ready to refresh its existing backup appliance and software to take advantage a new IBM Spectrum Protect features and STORServer’s turnkey solution.

Since the initial implementation STORServer completed for the regional transit agency in 2010, the features of the IBM Spectrum Protect, formerly IBM Tivoli Storage Manager (TSM), software have been enhanced, including the change of the underlying software database to DB2. The availability of this DB2 database, as well as IBM Spectrum Protect’s deduplication feature designed to reduce backup storage requirements, prompted DART to upgrade its existing storage configuration.

It was imperative to select the right partner for its backup needs, as DART relies heavily on the data collected and reported by its radio and CAD/AVL bus dispatch system. The data tracks important metrics like on-time performance, which is analyzed and used in planning for scheduling, route assignments, vehicle assignments and to make other critical decisions.

“Knowing our main priority was to ensure platform stability and system supportability, STORServer carefully considered our current needs while also recommending scalable solutions that will allow us to easily accommodate potential future needs as our backup requirements change over time,” said David Bauchert, senior control systems programmer, DART.

Because the existing configuration STORServer installed and implemented had worked with the agency’s backup needs for this dispatch system, DART’s IT team trusted STORServer’s recommendations for this upgrade.

The Solution

STORServer helped DART implement a new backup appliance and transition an existing tape library to serve as the DR target for its backup data:

Primary Backup: STORServer EBA852 – This enterprise backup appliance with SSDs enabled the agency to take advantage of new features, like deduplication, available in Spectrum Protect. The IBM Protect database is housed on SSDs in the appliance with faster processing power. In this configuration, 20TB of Storwize V3700 disk storage was included. The primary backup data is kept on disk for quick restore and to take advantage of Spectrum Protect’s deduplication feature, which reduces backup storage requirements. This configuration also includes Spectrum Protect Suite licensing, which offers simplified pricing and licensing with a tiered per-terabyte metric. This licensing enables the agency to have access to a suite of backup software products, including database and mail agents, along with Spectrum Protect for Virtual Environments, should the agency need to enable that in the future.
DR: IBM TS3100 Tape Library – This entry-level tape library, which was previously installed by STORServer in 2010, is used for DR copy purposes. Reusing this existing library provided flexibility and reduced the costs associated with the appliance server refresh. As part of the agency’s DR plan, the tapes are taken offsite every day. Incremental backups also take place daily. The appliance server and configuration recommended by STORServer allows DART to plan for future data growth, as additional external storage can be added as needed to the appliance server. With the newest Spectrum Protect and STORServer Console (SSC) versions included as part of this upgrade, DART can manage and move its data more efficiently. Scalable to future-proof the agency’s needs, Spectrum Protect also reduces backup and recovery infrastructure costs. SSC is designed to let administrators configure and manage their Spectrum Protect environment with a single, intuitive user interface. It also helps users save time, reducing daily administration tasks to less than 30 minutes per day.

The Results:

59% data deduplication savings for a deduplication ratio of 3:1
Even as DART experienced 40% data growth since the implementation, the deduplication capabilities enabled them to use 38% less storage.
Reduced overall costs for data protection by removing redundant data
Data is moved more efficiently, allowing for best implementation of data protection business practices.
Automated delivery of daily reports allows for easy review and confirmation that backups have completed successfully. These reports can be individually tailored and distributed to multiple levels within the organization.

“It’s been incredibly advantageous for us, both from a cost and time perspective, to have access to IBM Spectrum Protect’s deduplication capabilities. We’ve experienced substantial savings in storage since then. Previously, we were running at 100% of our disk capacity, and now we are only using 26% of it,” added Bauchert.
