1.6TB 12Gb SAS 2.5-Inch SSD From Toshiba

As well as SAS or SATA 4TB HDD

Toshiba Corporation has announced European availability of its enterprise PX02SMxxx SSDs and MG03ACAxxx SATA and MG03SCAxxx SAS HDDs.

toshiba_enterpriseclass_hdds_and_ssds

PX02SMx enterprise SSDs (eSSD) utilize 24nm eMLC  NAND technology and are available with capacities of 200GB (PX02SMF020), 400GB (PX02SMF040), 800GB (PX02SMF080) and 1.6TB (PX02SMB160). The drives feature a dual-port 12Gb/s SAS interface and support cryptographic erase. They incorporate Kingston’s proprietary Quadruple Swing-By Code (QSBC) for improved error correction and reliability.

Toshiba’s HDDs are supplied in a 3.5-inch (8.9 cm) form factor and have been designed to accommodate 24/7 operation and can be supplied with Toshiba’s Enhanced Secure Cryptographic Erase feature. The MG03ACAx series is equipped with a SATA interface and is available with capacities of 1TB (MG03ACA100), 2TB (MG03ACA200), 3TB (MG03ACA300) and 4TB (MG03ACA400). The MG03SCAx series is fitted with a SAS interface and is also available with capacities of 1TB (MG03SCA100), 2TB (MG03SCA200), 3TB (MG03SCA300) and 4TB (MG03SCA400).

SSD Specifications

Model Number
PX02SMF020 / PX02SMF040 / PX02SMF080 / PX02SMB160
Formatted Storage Capacity
200GB / 400GB / 800GB / 1.6TB
NAND
24nm eMLC (64GB/die)
Interface
SAS 6.0/12 Gbps
Random Read (4KB)
120,000 IO/s
Random Write (4KB)
25,000 IO/s
Sequential Read (64 KB)
900MB/s
Sequential Write (64 KB)
400MB/s
Form factor
2.5 inch
Height
7mm / 7mm / 7mm / 15mm
Width
69.85 mm
Depth
100.45 mm
Ambient Temperature (operating)
From 0°C to +55°C
Case Temperature (operating)
From 0°C to +60°C
Ambient Temperature (non-operating)
From -40°C to +70°C
MTBF
2,000,000 hours
Product Life
5 years

HDD Specifications

Model Number

  • SATA 2.6/3.0 Interface: MG03ACA100 / MG03ACA200 / MG03ACA300 / MG03ACA400
  • SAS 2.0 Interface: MG03SCA100 / MG03SCA200 / MG03SCA300 / MG03SCA400

Formatted Storage Capacity
1TB / 2TB / 3TB / 4TB
Rotational Speed
7,200 rpm
Interface Speed
1.5, 3.0, 6.0 Gbps
Data Buffer Size
64MB
Logical Data Block
512B
Form factor
3.5 inch
Height
26.1mm
Width
101.6 mm
Depth
147 mm
Weight (max.)
720g
Acoustics (Ready)
31dB
MTBF
1,200,000 hours
