NAB: Quantum With Purpose-Built 4K Video Reference Architectures

Quantum Corp. announced purpose-built 4K video reference architectures that leverage the company’s StorNext – powered, disk – and flash-based workflow storage systems to maximize 4K stream counts and optimize performance levels in accordance with users’ specific needs.

Click to enlarge

Based on testing with real-world metrics, this reference architectures reinforce company’s position as the performance provider in media workflows and empower media facilities to make better-informed investments in 4K storage infrastructure.

Need for purpose-built 4K video solutions
4K has become the primary driver of storage-purchasing decisions for many media companies, but identifying the best storage medium and system configuration is challenging. Given the variety of stream counts and media formats used across different facilities, it’s not necessarily obvious or intuitive what type of storage will deliver the best mix of performance, capacity and cost for a specific workflow or use case. To answer this question, the company conducted testing that provided a thorough performance characterization and also identified the optimal drive form factors for various media types.

Role of flash in media workflows
Flash can provide a tremendous amount of performance, and firm’s testing showed that it provides value in media workflows where there is a high number of compressed streams – which can leverage the random I/O performance of flash – and where high capacity is not as important. On the other hand, because of the nature of uncompressed formats, flash does not improve performance when there is a high number of uncompressed streams and may be capacity-limiting. StorNext performance optimization applies equally well to flash and disk, thereby giving users the freedom to choose the infrastructure that fits their performance, capacity and cost requirements.

Xcellis storage systems

Maximizing 4K storage performance and value
Company’s testing involved 14 different storage configurations using six media formats, all under real-world conditions – e.g., arrays filled to 85% of capacity and using high-quality RGB data, not the 30-percent-less-demanding YUV data often used by others for evaluation. From this testing, the firm determined stream counts and performance levels for its StorNext-powered disk drives and arrays, when and where flash is the most cost-effective solution for high performance, higher-resolution workflows, and when a spinning disk configuration can provide performance for less money – ultimately resulting in the creation of four 4K reference architectures. Based on StorNext-powered Xcellis storage systems, these reference architectures are sized for specific stream counts and can scale up as needed to provide additional capacity and performance.

StorNext Base 4K

StorNext Base 4K – For small workgroups working in compressed formats, supports up to 15 streams of compressed and two streams of full-aperture 10-bit uncompressed 4K.

StorNext High Capacity 4K

StorNext High Capacity 4K – Designed for groups that need additional capacity for primary storage, supports up to 24 streams of compressed and up to six streams of full-aperture 10-bit uncompressed 4K.

StorNext Performance Disk 4K

StorNext Performance Disk 4K – The starting point when higher stream counts and capacity are required, supports up to 28 streams of compressed and up to five streams of full-aperture 10-bit uncompressed 4K.

StorNext All Flash 4K

StorNext All Flash 4K – Providing maximum compressed stream counts and uncompressed support for high-value content production, supports up to 66 streams of compressed and up to six streams of full-aperture 10-bit uncompressed 4K. This all flash configuration will be on display in firm’s booth at the 2017 NAB Show.

Nick Gold, chief revenue officer, Chesapeake Systems LLC, said: “We’ve represented Quantum to our customers for years based on their technological strength and expertise in media workflows. I’m excited about the company’s 4K testing and new StorNext-powered reference architectures because my clients will appreciate that my recommendations are based on real-world data. That’s extremely valuable.“

Dave Frederick, senior director, media and entertainment, Quantum, said: “We have completed exhaustive testing of 4K media workflows and applications, arguably gaining the industry’s best view of how storage reacts in a 4K environment. With this knowledge, we can give customers a clear view of the most effective way to achieve their goals as they implement 4K workflows. By turning our findings into reference architectures that are easy to deploy and scale, we’re making it easy to implement 4K infrastructure and removing doubts about real-world performance and scalability.“
